    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution
    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution

    Bộ chuyển đổi USB to CAN Model A, STM32 Chip Solution

    538,000VNDLiên hệ

    Sản phẩm nhập khẩu chính hãng Waveshare

    Hỗ trợ kỹ thuật trong suốt quá trình sử dụng

    Xuất hóa đơn GTGT cho cá nhân, đơn vị có nhu cầu

    Sản phẩm được bảo hành 6 tháng


    Thông tin sản phẩm

    Hỗ trợ mua hàng : 02436.231.170 or 0984.058.846

    Tư vấn kỹ thuật Raspberry Pi và RS232/RS485 to Ethernet : 0862.628.846

    Tư vấn kỹ thuật Module khác : 0866.828.846 or 0862.998.846

    VUI LÒNG LIÊN HỆ ĐỂ ĐƯỢC HỖ TRỢ KỸ THUẬT  VÀ ĐẶT HÀNG TRỰC TIẾP


    GIẤY XÁC NHẬN MLAB LÀ ĐƠN VỊ PHÂN PHỐI CHÍNH THỨC (OFFICAL DISTRIBUTOR) CỦA WAVESHARE TẠI VIỆT NAM

    USB to CAN Adapter Model A, STM32 Chip Solution, Multiple Working modes, Multi-system Compatible

    USB to CAN Adapter Model A

    STM32 Chip Solution, Multi-system Compatible, Multiple Working modes





    Features at a glance


    - Supports CAN2.0A (standard frame) and CAN2.0B (extended frame)

    - CAN baud rate is configurable in the range of 5Kbps-1Mbps

    - Supports 4 working modes: normal mode, loopback mode, silent mode, silent loopback mode

    - Supports multiple CAN data sending modes: single frame, multiple frames, manually, regularly and cyclic sending

    - Supports multiple CAN data receiving modes: can be configured to only receive data from a certain ID, or specify ID to automatically answer the configured data

    - Data can be saved as TXT or Excel

    - Supports CAN bus detection for status checking

    - Sending/receiving CAN data with time scale, allows sequentially displaying

    - Baud rate of USB virtual COM port is configurable in the range of 9600 ~ 2000000bps (2000000bps by default)

    - Supports setting working parameters by configuration software or serial command, can be saved after power off

    - Adopts STM32 chip solution, stable and reliable communication

    - Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit

    - Comes with master computer software for Windows system, easy to use

    - Easy secondary development, just need to modify the sending and receiving commands


    Version Upgrade



    Primary Functions


    Collects data from CAN bus to PC via USB for transceiver control, data analysis,
    acquisition and monitoring of CAN bus network


    CAN Baud Rate Configurable


    CAN Baud Rate Is Configurable In The Range Of 5Kbps-1Mbps


    Support Windows And Linux System


    Support Windows XP/7/8/10/11 and Linux systems such as Raspberry Pi OS and Ubuntu under Jetson Nano, support secondary development

    Support Multiple Working modes



    Adopts STM32 Chip Solution


    Adopts the original STM32F103 chip, stable and reliable communication

    Interfaces Introduction



    Product Show




    Outline dimensions
